الوصف
يدعم بطاقة شبكة مزدوجة بسرعة 1000 ميجابت في الثانية يدعم واجهة RS-232 القياسية قرص صلب مدمج على مستوى المراقبة 3.5 بوصة، يدعم تخزين الصور بسعة كبيرة مجهزة بواجهة صوتية قياسية مقاس 3.5 مم، وواجهات HDMI/VGA
المواصفات
- Terminal
- CPUApollo Lake Platform Processor; 1.5 GHz
- Memory4 GB
- Storage1 x 3.5″ Surveillance-Level Hard Disk (Optional Capacity: 1T/2T/4T)
- Interface
- Indicator4 Indicators (1 x System Indicator, 1 x Hard Disk Status Indicator, 1 x Power Indicator, 1 x Alarm Indicator)
- Audio1-ch Audio Input (MIC IN)； 1-ch Audio Output (AUDIO OUT)
- Video Output1 x HDMI, 1 x VGA
- Alarm Input4-ch Alarm Input (ALARM IN), Voltage Range: 0 V to 60 V
- Alarm Output4-ch Alarm Output (ALARM OUT), Voltage Range: 0 V to 60 V
- RS-232RS-232 Interface
- RS-4852 x RS-485 Interface
- USB4 x USB 3.0 Interface
- Network Interface5 x 100 Mpbs/1000 Mpbs Self-Adaptive Interface, supporting connecting with switch; 1 x Independent 100 Mpbs/1000 Mpbs Self-Adaptive Interface, supporting network isolation
- Bracket
- MaterialBlack Aluminum Material
- General
- Working Temperature and Humidity-20 °C to 70 °C (-4 °F to 158 °F); 10 % to 95% (No Condensation)
- Power Supply12V DC /5A
- Power ConsumptionMax.: 50 W Average: 25 W
- Dimensions245 × 170 × 65 mm (9.65 × 6.69 × 2.56 inch)
- Weight2 kg (4.4 lb.)
- Weight (with Package)2.5 kg (5.5 lb.)
- Dimensions (with Package)450 × 240 × 105 mm (17.7 × 9.45 × 4.1 inch)
- MaterialBlack Aluminum Material
